Apply NowWoods S15CD
Flail Shredders S15CD
Woods shredders are ideal for residue management in row crop and non-row crop applications; such as grain stubble (rice and wheat), sweet potatoes, vegetable crops, milo, corn, and sorghum. Our shredder slashes biodegradable residue into small pieces which require less nitrogen to decay. This prepared rich organic matt... + Read More
Features
- High capacity gearbox with large oil volume reduces heat buildup, extending bearing and gear life
- Specially designed oil seal protectors prevent vines from encasing and damaging gearbox oil seals
- 12.75-inch diameter flail tubes with spiral mounted knives feature increased rigidity, resulting in smoother operation
Specs
| Minimum Tractor PTO HP | 90 |
| Working Width (in) | 183 |
| Overall Width (in) | 190 |
| Cutting Height (in) | 2 to 14 |
| Approximate Weight (lbs.) | 4,248 |
| Tractor PTO Speed (rpm) | 1,000 |
| Optional Hitches | 2-point, 3-point (quick-hitch compatible) pull |
| Driveline 2 Point and 3 Point | CAT 6 |
| Pull-type | CAT 6 CV |
| Knife Types | Double-edged L (6mm), double-edged HD-cotton Duraface® (8mm) L; cup or contour cup |
| Knife Retention | Bolt-on (no D-rings) |
| Knife Pattern | Spiral |
| Number of L Knives | 168 |
| Lift HP Required | 90 |
| Pull HP Required | 90 |
| Flail Tube Diameter (O.D.) (in) | 12.75 |
| Flail Tube Bearing Diameter (in) | 2.18 |
| Hood Type | Smooth, trilateral shape |
| Hood/Deck Thickness (in) | .18 (optional wearliner available) |
| End Plate Thickness (in) | 0.25 |
| Shielding | Rubber belting or steel flaps |
| Wheel Size (in) | 9.5L x 15 |
| Wheel Arm Types | Rigid strut or caster |
| Optional Friction Clutch | 24,000 lbs. inch rating |
| Automatic Clutch | 30,000 lbs. inch rating (1.75-inch 20 PTO only) |
