Apply NowPequea HR-939
Rotary Rakes HR-939
Pequea’s HR-939 Haymaker is simple, sturdy, and reliable. With a 9′ raking width, it is designed for small to mid-size farms but built to last. Like all Pequea Rotary Rakes, the rake features two walking beams and a lift cylinder to navigate any terrain.
Features
- The Standard Tandem Bogie Axle Provides smooth travel in rougher fields.
- Pitch adjustment is quick and easy. Using the crank on the front lift cylinder the rake is set and will always return to the raking position when lowered into raking position
- All units are equipped with a rear lift cylinder. The rake can be raised for clearing windrows or for transport in and out of fields.
- The HR939 has an easy to adjust curtain.
Specs
| Working Width | 10' 8" |
| Raking Width | 9' |
| Transport Width | 9' 4" |
| Gearbox | Enclosed Oil Bath |
| Gear Reduction | 7.9:1 |
| Number of Rotors | 1 |
| Tine Arms per Rotor | 9 |
| Double Tines per Arm | 3 |
| PTO HP Requirement | 30 HP - 540 RPM |
| Hydraulic Requirement | 6 GPM / 1200 psi |
| Direction of Raking Action | Left |
| Weight | 1,050 lbs. |
| Axle | Walking Beams |
| Tire and Wheel | 18.5 x 8 Flotation Tire on 4 Bolt Painted Steel Rim |
