Apply NowBrillion SL-3081
Turfmaker III Series SL-3081
The Turfmaker III Series is similar to the Turfmaker II Series in that these models feature large seed boxes and are used in high volume seeding operations. The Turfmaker III Series was added to the line of Landscape Seeders to offer varying seed rates for special operations such as the seeding of flax. These models ar... + Read More
Features
Turfmaker III Series
- 8', 10', 12' Three-Point Hitch and Pull-Type Models Available
- Specialized High Capacity Seed Meters for Seeding Grasses and Flax
- Three-Point Hitch - Cat. II Free Link
- Three-Point Hitch - Cat. II, IIIN Quick Coupler Hitch
- 9.5L x 15-6 Ply Tires on 8' Pull-Type Models
- 11L x 15-8 Ply Tires on 10' and 12' Pull-Type Models
- High Capacity Micro-Metered Large Seed Box
- Seed Box Sight Windows
- Electric Clutch Kit Standard
- 15.75" Gray Cast Iron Front Pulverizer Roller
- 11.5" Gray Cast Iron Rear Pulverizer Roller
- Greaseable Axle Bearings
- S-Tine Track Remover Kit Available
- Coil Tine Track Remover Kit Available
- Scraper Kit for Front Pulverizer Roller Available
- Seed Shaft Monitor Kit Available
Specs
| Model | SL-3081 |
| Approximate Weight | 2,438 lbs. (1,097 kg) |
| Working Width | 8 ft. 0 in. (2.4 m) |
| Transport Width | 11 ft. 5 in. (3.43 m) |
| Transport Height | 6 ft. 6 in. (1.98 m) |
| Road Clearance | 1 ft. 3 in. (0.38 m) |
| Overall Height | 5 ft. 3 in. (1.6 m) |
| Overall Length | 11 ft. 9 in. (3.58 m) |
| Seed Box | All Steel Construction with Cover |
| Seed Box Capacity - Meter Box | 15 bu. (529 l) |
| Seed Meters | High Capacity Meter |
| Seed Meter Drive | Ground Driven |
| Seed Meter Spacing | 4.25 in. (108 mm) |
| Seed Delivery | Broadcast with Wind Deflector Tray |
| Pulverizer Roller - Front | 15.75 in. (400 mm) Gray Cast Iron |
| Pulverizer Roller - Rear | 11.5 in. (292 mm) Gray Cast Iron |
| Pulverizer Axle Bearings | Greaseable |
| Pulverizer Axle Size - Front | 12.75 in. (324 mm) |
| Pulverizer Axle Size - Rear | 8.625 in. (219 mm) |
| Hitch | Pull-Type with Hydraulic Transport |
| Hydraulic Equipment | Cylinders with Hoses to Hitch Point |
| Tire Size | 9.5L x 15-6 Ply Implement Rib |
| S-Tine Wheel Track Remover | Optional |
| Coil Tine Track Remover | Optional |
| Front Roller Scraper Kit | Optional |
| Turfmaker Sprockets | Optional |
| Electronic Acre Meter | Optional |
| Seed Shaft Monitor Kit | Optional |
| Safety Warning Lights & SMV Emblem | Standard |
| Safety Chain Kit | Standard |
| Powder Coat Paint, Red | Standard |
| Horsepower Requirements | 6 to 8 HP (4.5 to 6 kW) per ft. |
| Recommended Operating Speed | 3 to 6 MPH (5 to 10 km/h) |
