SD Series, Double Gang Models SDP-6
The Brillion Pulverizer has been synonymous with quality seedbed preparation for well over 100 years.
Features
SD Series, Double Gang Models
- Double Roller Configuration - Same Foundation as on Brillion Sure Stand Seeders
- 6', 8', 10' or 12' Three-Point Hitch Models Available
- Pull-Type Models Available in 8', 10' or 12' Sizes
- Gray Iron Pulverizer Wheels with Larger Diameter Wheels on the Front Roller
Specs
| Model | SDP-6 |
| Approximate Weight | 845 lbs. (380 kg) |
| Working Width | 6 ft. 0 in. (1.8 m) |
| Transport Width | 7 ft. 0 in. (2.1 m) |
| Transport Height | 2 ft. 10 in. (.85 m) |
| Overall Length | 2 ft. 4 in. (.70 m) |
| Transport Tires | N/A |
| Pulverizer Wheels, Front Gang | 12 in. (300 mm) Gray Iron |
| Number of Wheels, Front Gang | 31 |
| Axle Size, Front Gang | 8.625 in. (216 mm) |
| Pulverizer Wheels, Rear Gang | 10 in. (250 mm) Gray Iron |
| Number of Wheels, Rear Gang | 32 |
| Axle Size, Rear Gang | 1.75 in. (43.75 mm) |
| Hitch | Cat. I Three-Point |
| LED Safety Warning Lights & SMV Emblem | SMV Emblem Only |
| Safety Chain Kit | N/A |
| Powder Coat Paint, Red | Standard |
| Horsepower Requirements | 35 HP (26.88 kW) and up |
| Recommended Operating Speed | 3 to 6 MPH (5 to 10 km/h) |
